AI Predictive Flow (Zeiierman) is a pattern-based oscillator that estimates future price direction by comparing the current market state to similar historical conditions.
Instead of relying on traditional indicators like momentum or moving averages alone, the script builds a multi-feature representation of price behavior and uses a k-Nearest Neighbors (kNN) model to identify past patterns that closely resemble the present.
From those matches, it derives an expected forward return, which is then transformed into a smooth oscillator and a predicted trend regime.
The result is a forward-looking signal that reflects a data-driven expectation based on similar past patterns, not just current price movement.
█ How It Works
⚪Feature Extraction (Market State Model)
The script converts price into a compact feature set that describes the current market state.
It uses four core features:
- Short-term return
- Momentum
- RSI bias
- EMA spread
These are created inside the feature function:
feat(shift, mode) =>
c = close[shift]
c1 = close[shift + 1]
cm = close[shift + momLn]
ef = ta.ema(close, fLen)[shift]
es = ta.ema(close, sLen)[shift]
r = ta.rsi(close, rsiLn)[shift]
float v = 0.0
if mode == 1
v := c1 != 0 ? math.log(c / c1) : 0.0
else if mode == 2
v := cm != 0 ? (c - cm) / cm : 0.0
else if mode == 3
v := (r - 50.0) / 50.0
else
v := c != 0 ? (ef - es) / c : 0.0
v
Each feature captures a different dimension of price behavior:
- return measures immediate movement
- momentum measures directional displacement
- RSI bias measures internal pressure
- EMA spread measures trend structure
These values are then stacked across multiple bars to form the pattern used for comparison.
⚪Pattern Memory (Historical Pattern Library)
The script stores rolling sequences of each feature into separate matrices so the current market state can be compared against past states.
That process is built here:
pushFeat(mat, mode) =>
vals = array.new<float>(tot, 0.0)
for i = 0 to tot - 1
array.set(vals, tot - 1 - i, feat(i, mode))
cur = array.slice(vals, tot - len, tot)
old = array.slice(vals, 0, len)
matrix<float> out = matrix.new<float>(1, len, 0.0)
for i = 0 to len - 1
matrix.set(out, 0, i, array.get(cur, i))
hist = array.new<float>(len, 0.0)
for i = 0 to len - 1
array.set(hist, i, array.get(old, i))
if mat.rows() >= mem
mat.remove_row(0)
mat.add_row(mat.rows(), hist)
out
This creates:
- a current feature row
- a rolling history of prior feature patterns
So rather than comparing single-bar values, the model compares multi-bar pattern structure.
⚪Pattern Matching Engine (kNN Distance Model)
Once the current feature pattern is built, it is compared to all stored historical patterns.
Distance is measured feature-by-feature across the full pattern length:
getDist(matrix<float> a1, matrix<float> a2, matrix<float> a3, matrix<float> a4, matrix<float> b1, matrix<float> b2, matrix<float> b3, matrix<float> b4) =>
out = array.new<float>(b1.rows(), 0.0)
for i = 0 to b1.rows() - 1
s = 0.0
d1 = a1.diff(b1.submatrix(i, i + 1)).row(0)
d2 = a2.diff(b2.submatrix(i, i + 1)).row(0)
d3 = a3.diff(b3.submatrix(i, i + 1)).row(0)
d4 = a4.diff(b4.submatrix(i, i + 1)).row(0)
for j = 0 to len - 1
s += math.pow(d1.get(j), 2) * 0.25 +
math.pow(d2.get(j), 2) * 0.25 +
math.pow(d3.get(j), 2) * 0.25 +
math.pow(d4.get(j), 2) * 0.25
out.set(i, math.sqrt(s))
out
This produces a similarity score for every stored pattern. A smaller distance means the past setup looked more like the present one.
⚪Prediction Model (kNN Forward Expectation)
After the distances are ranked, the script selects the nearest neighbors and averages their future outcomes.
The kNN model is implemented here:
knn(dist, n) =>
ix = dist.sort_indices()
useN = math.min(n, ix.size())
sumD = 0.0
avg = 0.0
for i = 0 to useN - 1
sumD += dist.get(ix.get(i))
if useN > 0
for i = 0 to useN - 1
d = dist.get(ix.get(i))
w = useN > 1 ? (sumD != 0 ? (1 - d / sumD) : 1.0) : 1.0
avg += Y.get(ix.get(i)) * w
avg
The forward return used for comparison is defined here:
y := math.log(base) - math.log(base[ahead])
This represents the forward return following each historical pattern. The result is a weighted expectation of future movement, not just a reading of current trend.
⚪Predictive Oscillator
The raw kNN prediction is smoothed and transformed into the main oscillator and signal line.
pred_ = ta.ema(pred, smth)
if not na(pred)
predSm := smth > 1 ? pred_ : pred
osc = ta.ema(predSm, oscLn)
sig = ta.ema(osc, sigLn)
hist = osc - sig
This creates:
- Oscillator = smoothed expected return
- Signal line = secondary smoothing for crossover confirmation
- Histogram = distance between oscillator and signal
⚪Predicted Trend Regime
Beyond the oscillator, the script also builds a broader trend regime using the predicted price path.
First, the raw prediction is converted into a projected price line:
predLine := base + base * (math.exp(pred) - 1)
Then a regime band is created using ATR:
hiRef = predLine + bandM * atr
loRef = predLine - bandM * atr
if ta.highest(hiRef, regLn) == hiRef
trendUp := true
if ta.lowest(loRef, regLn) == loRef
trendUp := false
This background state represents:
- bullish predicted regime when the projected path is pressing into new highs
- bearish predicted regime when the projected path is pressing into new lows
So the background is not showing the raw price trend. It is showing the model’s predicted regime bias.
█ How to Use
⚪ Read the Oscillator
- Above 0 → bullish expectation
- Below 0 → bearish expectation
- Near 0 → neutral/low conviction
- Far from 0 → strong directional push
Use crossovers for entry timing:
- Bullish crossover → potential upward continuation
- Bearish crossover → potential downward continuation
⚪ Use the Predicted Trend Regime
The background highlights the model’s broader directional bias:
- Green → predicted bullish regime
- Red → predicted bearish regime
Regime shifts often indicate:
- early trend transitions
- continuation confirmation
- structural changes in expectation
⚪ Combine Signals
Best use comes from alignment:
- Oscillator above zero + bullish regime + signal → strong continuation bias
- Oscillator below zero + bearish regime + signal → strong downside bias
- Divergence between the two → caution / mixed signals
█ Settings
- Pattern Length – Controls how many bars define the current pattern. Higher values capture more structure, lower values increase responsiveness.
- Memory Size – Number of historical patterns stored for comparison. Larger values improve context but increase computation.
- Neighbors (k) – Number of closest matches used in prediction. Lower values are more reactive, higher values are smoother.
- Prediction Smoothing – EMA smoothing applied to the raw prediction. Reduces noise at the cost of lag.
- Signal Length – Smoothing of the signal line used for crossover signals.
-----------------
